Description

The Dell PowerEdge R7525 is a powerful 2U rack server designed for demanding workloads. Featuring dual 2nd or 3rd Generation AMD EPYC processors, extensive memory capacity, and flexible storage options, the R7525 excels in virtualization, data analytics, and software-defined storage environments. Its robust architecture and advanced management capabilities make it a reliable choice for modern data center.

Specifications:

• Processor:
  • Two 2nd or 3rd Generation AMD EPYC Processors
  • Up to 64 cores per processor
• Memory:
  • DDR4 Memory at up to 3200 MT/s

  • Up to 32 x DDR4 DIMMs
  • Supports RDIMM (up to 2TB) and LRDIMM (up to 4TB)

• Storage Controllers:
  • HBA345, PERC H345, PERC H745, SATA/SW RAID (S150), H755, H755N
• Storage:
  • Front Bays:
    • Up to 24 x 2.5″ with up to 24 NVMe, SAS/SATA (SSD/HDD)
    • Up to 12 x 3.5″ SAS/SATA (HDD)
    • Up to 16 x 2.5″ SAS/SATA (SSD/HDD)
  • Rear Bays:
    • Up to 2 x 2.5″ SAS/SATA (HDD/SSD)
    • BOSS-S2 for up to 2x M.2 SATA SSDs
• PCIe: Up to 8 x PCIe Gen4 slots
• Power Supplies:
  • 800W Platinum
  • 1400W Platinum
  • 2400W Platinum
• Cooling :
  • Hot-Plug Fans: Standard (STD), High Performance (HP), or Very High Performance (VHP)
  • Optional direct liquid cooling solution with  leak detection via iDRAC managed by Liquid Leak Sensor (LLS). Requires additional equipment
• Dimensions:
  • Height: 2U / 86.8mm (3.42″)
  • Width: 434.0mm (17.09″)
  • Depth: 736.29mm (28.99″)
  • Weight: 36.3KG (80lb)
• Form Factor:  2U Rack Server
• Embedded Management:
  • iDRAC9
  • iDRAC RESTful API with Redfish
  • iDRAC Direct
  • Optional Quick Sync 2 BLE/wireless module
• Bezel:
  • Optional LCD bezel
  • Optional Security bezel
• Security:
  • Cryptographically signed firmware
  • Secure Boot
  • Secure Erase
  • Silicon Root of Trust
  • System Lockdown (requires OpenManage Enterprise)
  • TPM 1.2/2.0, TCM 2.0 optional
  • AMD Secure Memory Encryption (SME)
  • AMD Secure Encrypted Virtualization (SEV)
• Embedded NIC: 2 x 1GE LOM
• Networking Options: OCP x16 Mezz 3.0
• GPU Options: Up to three double wide 300W or six single wide 75W accelerators
• Ports:
  • Front Ports: 1 x Dedicated iDRAC direct micro-USB, 1 x USB 2.0, 1 x VGA
  • Internal Ports: 1 x USB 2.0
  • Rear Ports: 1 x USB 2.0, 1 x Serial (optional), 1 x USB 3.0, 1 x Ethernet, 1 x VGA, 1 x Power Button
• Rails:
  • Type B6 Sliding ReadyRails II for 4 post racks
  • Type B4 Stab-in Static ReadyRails for 2 or 4 post racks
  • Type B13 Drop-in/Stab-in Generic Tool-less for 4 post racks
  • optional cable management arm (CMA) or strain relief bar (SRB) available on some rail kits
